FEATURES
- As it is a PTO driven Implement, it is the fastest method to dig holes in farm Land.
- It can dig holes from diameter 8” upwards.
- Suitable for harsh operating conditions.
- It has special steel cutting tip with semi-double flighting which handles tough Soil conditions.
- It has heavy duty gear box & PTO shaft with shear bolt for overload protection.
- It can make hole up to 30” to 35” deep.
- It consist with 5 pcs such as Gear Box, PTO Shaft, Auger Unit, Holding Bar and Frame.
SPECIFICATIONS
| Frame | Heavy duty rectangular pipe |
| Hitch | Category 2 |
| Gear box | Compatible with 55 HP max. ,with 3:1 ratio |
| Out put shaft | 2” (50 mm) |
| Input RPM | 540 |
| PTO | Clutch type |
| Flighting | Semi – Double |
| Accessories (Optional) | Storage stand |
| Auger length | 43” (1100mm) |
| Tractor Power (hp) | 40 and Above |
AUGERS
| Auger sizes | Weight (Kg. Approx) |
| 8” | 140 |
| 10” | 145 |
| 12” | 147 |
| 16” | 170 |
| 20” | 210 |
