FEATURES
- The Ground Clearance from under frame & unit-to-unit clearance are adequate to cope with trashy Conditions
- Adding an extra furrow or Repositioning unit to allow for extra clearance is quick & easy
- The plough has Robust Steel Blade with bar points for toughest ploughing jobs
- Bar point having longer life, as they can be extended till the last possible length
- The working of the plough is controlled by hydraulic system of the tractor
- Gives very good inversion & penetration of soil & tougher ploughing job
- Designed to work in all types of soil
- Soil Breaking, Raising & Turning can be done
- It can be used in stony & rooted soil too
SPECIFICATIONS
| Model | ALMB |
| Frame | 80x80x7 mm (Sq. Tubular Box) |
| Furrow | 2, 3 |
| Width Of Cut | 610mm |
| Depth Of Cut | 350mm |
| Blade | 10mm |
| Mould Board | 8mm |
| Bar Point | 40x25mm Bar(Forged) |
| Draw Bar Rod | 50 mm (Solid) |
| Tyne | 36 mm Profile Cut Single Piece |
| 3 Point Linkage Lever & Connecting Rod | 65x16mm Flat & 32 Square |
| Length (mm Approx) | 1300 |
| Height (mm Approx) | 1060 |
| Weight (kg Approx) | 200 |
| Tractor Power ( Hp) | 45 & Above |
