FEATURES
- Used in open field workings for the superficial ploughing , shattering of clods, preparation of soil for sowing, burial of organic substances & remains
- It can be easily transported on the tyres using the hydraulic system
- High quality boron steel disc with 48 – 52 HRC hardness
- Effectively break up heavy clods because of sturdy design and weight
- Bearing spools for better lubrication and less load on tractor
- High quality seals are used to prevent the bearing & hub from mud & water entry
- Extra heavy duty hydraulic harrow comes with optional accessories i.e. dead weight & crumbler
SPECIFICATIONS
| Model | AL-20-HYD |
| Frame | Square Tube 132x132x7mm |
| Gang Bolt/Axle (mm) | 40 (solid sq.rod) |
| Gangs | 2 (10 x 10) With Hex Type Spool bearings |
| No. of Disc | 20 |
| Type of Disc | Notched Discs & Plain Discs |
| Center Hole | 90 MM Hex |
| Disc Diameter | 610 (24″) X 5MM |
| Cutting Width | 2300 mm Approx. |
| Distance Between Discs | 228 mm |
| Linkage | Draw Bar |
| Bearing Hubs | 8 |
| Wheels | 2 nos (7.50 x 16) |
| Jack | Double action single jack |
| Tyre Size | 10.0/75 – 15.3 & 13.0/55-16(14PR) |
| Operation | Hydraulic |
| Weight | 1600 Kg |
| Tractor Power (Hp) | Above 75 |
